TP-Link Vigi PS90 Solar Panel Charge Regulator - IP66 - 10.95V Voltage - 93.6Ah Lithium Battery - MPPT Controller - Smart Auxiliary Heating - White Colour

The VIGI solar system controller is the ultimate solution for efficiently managing and maintaining your solar energy system. Designed with advanced technology, this controller enables remote management via the VIG app or VIGI Cloud VMS, providing real-time control and monitoring from anywhere. Its compatibility with high-capacity automotive-grade lithium batteries ensures durable, safe performance, even in extreme conditions, thanks to its independent protection circuit and smart auxiliary heating technology.
This system is equipped with an MPPT charge controller that increases charging efficiency by 20%, optimizing solar energy capture and extending battery life. IP66-certified weatherproofing ensures reliable outdoor operation, withstanding harsh weather conditions. It also has multiple smart features, such as over-discharge protection, charge and discharge control, temperature management, and the ability to perform remote firmware updates, all to ensure optimal performance and safe, simple operation.
Its compact, sturdy design, together with easy installation on poles of different diameters, make it a versatile option for solar projects of any scale. The intuitive interface, LED indicators and advanced management features allow for complete system control, including scheduling, battery status monitoring, and load management. With CE, FCC, RoHS certifications and IP66 resistance, the VIGI Controller is the perfect choice for anyone seeking efficiency, safety and reliability in remote, high-demand solar systems.
Features:
-Solar system controller with remote management via VIG or VIGI Cloud VMS
-93.6Ah/10.95V automotive-grade lithium battery with independent protection
-Smart auxiliary heating technology for cold climates
-MPPT charge controller that increases efficiency by 20%
-IP66-certified weatherproof
-Smart features: over-discharge protection, temperature control, remote updates
-Real-time monitoring, load management and advanced scheduling
-Compatible with poles with a diameter of 80 to 160mm
-Compact dimensions and easy outdoor installation
Specifications:
-Type: Lithium
-Battery capacity: 93.6Ah (max), 31.2Ah per lithium battery
-Voltage: 10.95V
-Maximum output voltage: 12.6V
-Lifespan: over 500 cycles
-Product dimensions: 18.9×6.4×16.8 inches (481×163×426 mm)
-Battery dimensions: 9.4×2.9×2.8 inches (240×74×72 mm)
-Charging conditions: 0 °C to 45 °C, with smart auxiliary heating from -30 °C to 45 °C
-Discharge conditions: -20 °C to 60 °C, with smart auxiliary heating from -30 °C to 60 °C
-Interface: three-pin connectors, four-pin connectors, RJ45, and DC power connectors
-LED indicators: 6 (SYS, LAN, PV, BAT) in blue
-Charge control: three-way
-Protection against high and low temperatures, over-discharge
-Real-time power consumption and monitoring
-Account management, remote update and reset
-Certifications: CE, FCC, RoHS, IP66
-Weight: 24 kg
