Asus Prime B860M-PLUS WIFI LGA 1851 Motherboard - WiFi, Bluetooth, 4x DDR5, 2x M2, 4x SATA III, PCIe 4.0, 5.0, USB 2.0, 3.2, USB-C, RJ-45, HDMI, DisplayPort - ATX Form Factor

ASUS PRIME series motherboards are expertly designed to unleash the full potential of the latest Intel Core Ultra processors (Series 2). With a robust power design, comprehensive cooling solutions, and smart tuning options, the PRIME B860-PLUS WIFI motherboard gives users and PC builders a range of performance optimizations through intuitive software and firmware features. It is designed to be compatible with advanced AI PCs, offering the power and connectivity needed for demanding AI applications.
Specifications:
Processor:
-Processor manufacturer: Intel
-Processor socket: LGA 1851 (Socket V1)
-Compatible processor: Intel Core Ultra (Series 2)
-Supported processor sockets: LGA 1851
Memory:
-Compatible memory types: DDR5-SDRAM
-Number of memory slots: 4
-Memory slot type: DIMM
-Memory channels: Dual channel
-ECC compatibility: Non-ECC
-Maximum internal memory: 256 GB
-Unbuffered memory: Yes
Storage controllers:
-Supported storage drive types: HDD & SSD
-Supported storage disk interfaces: M.2, SATA III
-Number of supported HDDs: 4
-Number of compatible storage drives: 6
-RAID support: Yes
-RAID levels: 0, 1, 5, 10
Graphics:
-Parallel processing support: Not supported
Internal I/O:
-USB 2.0 connectors: 1
-USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
-USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
-Number of SATA III connectors: 4
-S/PDIF output connector: Yes
-Front panel audio connector: Yes
-Front panel connector: Yes
-ATX power connector (24-pin): Yes
-CPU fan connector: Yes
-Number of chassis fan connectors: 4
-Chassis intrusion connector: Yes
-Number of COM connectors: 1
-TPM connector: Yes
-Thunderbolt headers: 1
-12V power connector: Yes
-RGB LED strip connector: Yes
Rear panel I/O ports:
-Number of USB 2.0 ports: 4
-Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 1
-Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports: 2
-Number of USB 3.2 Gen 2x2 Type-C ports: 1
-Ethernet LAN (RJ-45) port count: 1
-Number of HDMI ports: 1
-Number of DisplayPorts: 1
-WiFi-AP antenna connector: 1
Connectivity:
-Ethernet: Yes
-Ethernet interface type: 2.5 Gigabit Ethernet
-Wi-Fi: Yes
-Wi-Fi standard: Wi-Fi 6E (802.11ax)
-Wi-Fi standards: Wi-Fi 6E (802.11ax)
-Bluetooth: Yes
-Bluetooth version: 5.3
Features:
-Chipset: Intel B860
-Audio output channels: 7.1 channels
-Component for: PC
-Form factor: ATX
-Chipset family: Intel
-Supported Windows operating system: Windows 10 x64, Windows 11
Expansion slots:
-PCI Express x16 (Gen 4.x) slots: 4
-PCI Express x16 (Gen 5.x) slots: 1
-Number of M.2 (M) slots: 2
-1st M.2 largest key size: 2280
-1st M.2 highest PCI Express generation: 5.0
-2nd M.2 largest key size: 2280
-2nd M.2 highest PCI Express generation: 4.0
BIOS:
-BIOS types: UEFI AMI
-BIOS memory size: 256 MB/s
Weight and dimensions:
-Width: 305 mm
-Depth: 244 mm
